John Deere 9RT 590 Tractor available through IPSO

Overview:

  • Maximum engine power: 649 hp (477 kW) (ECE-R120)
  • 13.4L 6-cylinder engine
  • Weight and wheelbase: 20.6 t and 2.947 m
  • Exclusive AirCushion suspension—standard on the base model—isolates the tractor from sudden bumps during operation.

The 9RT 590 is perfect for heavy straight line pulling applications in fields with light soil, limited side hill slopes and large enough headlands to allow soft turns without too much soil scrubbing.

See product specifications See product brochure

Why 9RT 590?

Efficient Power And Transfer

Benefit from the total reliability and excellent fuel economy of our 13.6 l JD14 engine and effectively manage its huge power reserves and up to 2723 Nm torque with the e18™ transmission.

John Deere 9RT tractor with dual rubber tracks shown from a front-right angle on a white background, featuring a full cab and front weight

9 Series Cab – Your Favourite Place

Enjoy an outstanding cab featuring the G5Plus CommandCenter™ and numerous comfort features such as 6.5” digital touchscreen radio with Apple CarPlay & Android Auto integration, 6.1 sound system and the AirCushion suspension system with 340 mm suspension travel.

Interior of the cab on a 9R Series Tractor

Next-Level Automation

Achieve unprecedented levels of productivity from our in-base AutoTrac, Variable Rate Application, Section Control, and advanced licences like AutoTrac™ Turn Automation, AutoTrac™ Implement Guidance Passive, AutoPath™, MachineSync, and In-Field Data Sharing.

Field, 9RT Series Tractors

Technical Specifications

Key Features
Pump Rated Output
Standard: 208 L/min 55 gpm Optional: 416 L/min 110 gpm
Base Machine Weight
21512 kg
Engine Model
JD14
Displacement
827 see you in
Rated Engine Power
582 hp
Rated Engine Power
590 PS
Maximum Engine Power
477 kW
Rear Hitch Category (SAE Designation)
Category 4N/N
Base Machine Weight
47326 lb
Engine Make
John Deere JD14 engine (B20 diesel compatible)
Engine Family
MJDXL13.5334
Displacement
13.6 L
Rated Engine Power
434 kW
Maximum Engine Power
640 hp
Maximum Engine Power
649 PS
Transmission Type
John Deere e18™ 18-speed PowerShift™ with Efficiency Manager: 40 km/h (25 mph)
Rear Power Take-Off (PTO) (6) ▾
Leave category
Independent, 44 mm (1.75 in.) 20-spline, 1000 rpm
Rated PTO Power
249 kW
Engagement Method
Electrohydraulic
Rated PTO Power
335 hp
Rated PTO Power
340 PS
Number of Splines
20
Hydraulics (5) ▾
Hydraulic System Type
Closed-centre, pressure-and-flow compensated
Number of Rear Selective Control Valves (SCVs)
Four to six factory or field installed Base: four 1.3-cm (1/2-in.) couplers Optional: five to six 1.3-cm (1/2-in.) couplers factory installed Optional: three 1.9-cm (3/4-in.) couplers plus five 1.3-cm (1/2-in.) couplers factory installed
SCV Control
Electronic
Pump Rated Output
Standard: 208 L/min 55 gpm Optional: 416 L/min 110 gpm
Available Flow at a Single Rear SCV
1.3-cm (1/2-in.) couplers: 132 L/min 35 gpm 1.9-cm (3/4-in.) couplers: 170 L/min 45 gpm
Dimensions & Weights (10) ▾
Wheelbase
116 in
Base Machine Weight
47326 lb
Overall Length
274.2 in
Drawbar Ground Clearance
15 in
Maximum Ballast Level
54000 lb
Wheelbase
2947 mm
Base Machine Weight
21512 kg
Overall Length
6965 mm
Drawbar Ground Clearance
381 mm
Maximum Ballast Level
24494 kg
Engine (25) ▾
Engine Make
John Deere JD14 engine (B20 diesel compatible)
Engine Family
MJDXL13.5334
Displacement
827 see you in
Aspiration
Dual series turbocharger with fixed geometry first stage and variable geometry second stage - air-to-air aftercooling
Cylinder Liners
Wet-liner
Rated Engine Speed
2100 rpm
Rated Engine Power
434 kW
Engine Torque at Rated Speed
2008 lb-ft
Maximum Engine Power
640 hp
Maximum Engine Power
649 PS
Alternative Fuel Type
B30 Diesel Compatible
Fuel type
Diesel
Torque Rise
38 %
Engine Model
JD14
Emissions Certifications
Stage II, Stage IIIA, Stage V
Displacement
13.6 L
Number of Cylinders
6
Aftertreatment Type
Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF)/selective catalytic reduction (SCR)
Rated Engine Power
582 hp
Rated Engine Power
590 PS
Engine Torque at Rated Speed
2723 Nothing much
Maximum Engine Power
477 kW
Maximum Engine Torque
At 1550 rpm: 2723 Nm 2008 lb-ft
Power Bulge
10 %
Alternative Fuel Type
B20 diesel compatible
Electrical System (5) ▾
Battery Voltage
12 V
Alternator output
Standard: 250 amp Optional: 330 amp
Driving Lights
Halogen, 65 W; Optional: LED
Battery Cold Cranking Amps
2850 CCA
Working Lights
Standard: 20 halogen; Optional: 20 or 24 LED
Rear Hitch (3) ▾
Rear Hitch Category (SAE Designation)
Category 4N/N
Sensing Type
Electrohydraulic with draft sensing
Maximum Lift Capacity Directly at Coupling Points
20.000
Rear Axle (1) ▾
Final Drive
Outboard planetary
Operator Station (10) ▾
Seat Suspension
Air suspension
Degree of Seat Swivel, Right Hand
25 degree
Primary Display
G5ᴾˡᵘˢ CommandCenter™: 32.5 cm (12.8 in.)
Cabin volume
115 cu ft
Cab Glass Area
71.47 sq ft
Degree of Seat Swivel, Left Hand
8 degree
Instructional Seat
Standard
Radio
Standard: AM/FM, remote control, auxiliary input jack, four speakers, and external aerial Optional: Touchscreen radio with smartphone interface and voice recognition, Digital Radio (DAB+) with Radio Data System (RDS), auxiliary input jack, USB audio & video input, and Bluetooth microphone, six-speaker system (four speakers and two tweeters) and one subwoofer
Cabin volume
3.27 m³
Cab Glass Area
6.64 m²
Capacities (10) ▾
Fuel Tank Capacity
350 lass
Diesel Exhaust Fluid (DEF) Tank Capacity
24.8 lass
Cooling System Capacity
14.9 lass
Transmission - Hydraulic System
With 3-point linkage and PTO: 81.3 Without 3-point linkage and PTO: 79.3 lass
Crankcase oil capacity
16.9 lass
Fuel Tank Capacity
1324 L
Diesel Exhaust Fluid (DEF) Tank Capacity
93.9 L
Cooling System Capacity
56.5 L
Transmission - Hydraulic System
With 3-point linkage and PTO: 338 Without 3-point linkage and PTO: 330 L
Crankcase oil capacity
64 L
Transmission (2) ▾
Transmission Type
John Deere e18™ 18-speed PowerShift™ with Efficiency Manager: 40 km/h (25 mph)
Maximum Speed Forward
40 km/h 25 mph
Steering & Brakes (1) ▾
Steering Type
Heavy-duty steering pump: 130 cc 7.9 cu in.
Technology Integration (3) ▾
Guidance
Integrated StarFire™ Receiver with AutoTrac™ Activation, Section Control, Variable Rate, Documentation, Data Sync, Over-the-Air Updates, Remote Display Access
Remote Diagnostics
Available with activated JDLink hardware and activations
Connectivity
Available with JDLink™ hardware, activations, and Ethernet harnesses (availability dependent upon destination)
Drawbar (2) ▾
Drawbar Category
Standard: Category 5 with heavy-duty drawbar support Optional: Category 5
Maximum Vertical Load
12,000 lb (5,440 kg)
Additional Information (2) ▾
Country of manufacture
USA
Date Collected
28 February 2024
Machine Configuration (2) ▾
Wheel or Track Configuration
2-Track
Drive Type
4WD
Tracks (3) ▾
Track Tread Spacing
2,698 mm 106 in.
Number of Mid Rollers
Four
Track Width
Standard: 762 mm 30 in. Optional: 914 mm 36 in.
